AK12H0146

HANDLE 0-I (0 12h - 60º) IP69K BLACK/GREY FOR SIZE D2, D3 PADLOCKABLE
IP69K safety handle unit designed in accordance with the hygiene requirements of standard EN 1672-2. Composed of a pre-assembled handle unit and two fixing pieces. The pre-assembled handle consists of a black knob set in a grey plate with a two-component inner gasket plus a compression gasket for fixing to the mounting surface. The pre-assembled handle has protruding screws to engage with a fixing piece located inside the panel. A second fixing piece is assembled to the front block of the switch to be able to mount it on the handle fixed to the panel. It uses high performance plastics with antimicrobial technology and is resistant to highly polluted environments. Extreme shock resistance. The two-component internal gasket eliminates friction wear and guarantees the protection level is maintained over time. The front plate has two holes to insert padlocks up to 8mm in diameter. For size D2 and D3 switches. Frontal pad printing 0-I (0 12h – 60º).
Code 009AK12H0146
EAN 8430892313902
Logistic Data
Customs code 85365080
Technical data
Impact protection IK IK10

Handles IP69K - A solution for heavy-duty cleansing environments
